CE15JNS3AB - Cutler Hammer 60A 600V 3-Pole Freedom Series Contactor with 110-120VAC Coil

CE15JNS3AB

CE15JNS3AB is a Cutler Hammer Freedom Series 3-pole contactor rated for 60 amps and 600 volts with a 110-120VAC coil.

This Eaton XT IEC contactor features a 3-pole, non-reversing design with a frame size J, suitable for motor control applications up to 5 horsepower. It operates at 50-60 Hz frequency and includes a single normally open (1NO) contact configuration. The contactor is side-mountable and UL listed, CSA certified, and IEC rated for reliable industrial use.

Key Specifications
• Amperage Rating: 60A continuous
• Voltage Rating: 600V AC
• Number of Poles: 3-pole
• Coil Voltage: 110-120VAC, 50-60 Hz
• Frame Size: J
• Horsepower Rating: 5 HP max
• Contact Configuration: 1 Normally Open (1NO)
• Mounting Type: Side mount
• Operation: Non-reversing
• Series: Freedom
• Certifications: UL Listed, CSA Certified, IEC Rated
• No overload relay included

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 110 VAC coil.

Specifications

• Part Number: CE15JNS3AB
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : Freedom Series
• Type : CE15JN
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• Configuration : Non-Reversing
• Aux Contacts : 1 NO
• Coil Voltage Maximum : 120
• Coil Voltage Minimum : 110
• Frequency : 50 Hz

Product Data

• UPC : 782113980935
• GTIN : 00782113980935
• Country of Origin : Dominican Republic
• Dimensions : 4.22 in x 4.27 in x 2.56 in (Length/Depth x Height x Width)
• Weight : 2.12
• Certification : CSA Certified,UL Listed,IEC Rated,ISO 9000,DIN VDE 0600
