CE15HN3AB - Cutler Hammer 3 Pole 44A 110-120VAC Non-Reversing IEC Contactor

CE15HN3AB

CE15HN3AB is a 3 pole, 44A, 110-120VAC non-reversing IEC contactor designed for motor control applications. This Cutler Hammer contactor features a steel mounting plate and is suitable for use in a variety of industrial environments. The CE15HN3AB provides reliable switching for three-phase motors with a continuous current rating of 44 amps and a coil voltage of 110-120VAC at 50/60Hz. It is part of the Freedom series, frame size 140 mm, and is certified by CSA, UL, and IEC standards. This contactor does not include an overload relay and is non-reversing for straightforward motor control.

• Part Number: CE15HN3AB
• Manufacturer: Cutler Hammer
• Amperage Rating: 44A
• Coil Voltage: 110-120VAC, 50/60Hz
• Number of Poles: 3
• Mounting Type: Steel mounting plate
• Series/Frame: Freedom, Frame H, 140 mm
• Operation: Non-reversing
• Interrupt Rating: Not specified
• Trip Unit: No overload relay
• Certifications: CSA Certified, UL Listed, IEC Rated
• HP Rating: 3 hp

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 110 VAC coil.

Specifications

• Part Number: CE15HN3AB
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Voltage : 1
• Amperage : 44
• Phase : 3
• Poles : 3
• Configuration : Non-Reversing
• Coil Voltage Maximum : 120
• Coil Voltage Minimum : 110
• Frequency : 50 Hz

Product Data

• UPC : 78211397328
• GTIN : 00782113973289
• Country of Origin : Dominican Republic
• Dimensions : 4.22 in x 4.27 in x 2.56 in (Length/Depth x Height x Width)
• Weight : 2.12
• Certification : CSA Certified,UL Listed,IEC Rated,DIN VDE 0600,ISO 9000
