Product Info
- Manufacturer:Eaton
Description
CCV3175SR01
CCV3175SR01 is an Eaton CCV tenant main molded case circuit breaker rated at 175A, 3-pole, 240V with 10 kAIC interrupt rating and 120V shunt trip.This UL 489 listed breaker features line/load lugs, accepts #2/0-300 kcmil Cu/Al wire (60/75°C), and is designed for Type ECC Unit Enclosures as a tenant main circuit breaker.Key Specifications
- Part Number: CCV3175SR01
- Manufacturer: Eaton
- Amperage Rating: 175 A
- Voltage Rating: 240 V
- Poles: 3
- Interrupt Rating: 10 kAIC
- Shunt Trip: 120 V
- Wire Size: #2/0-300 kcmil Cu/Al
Specifications
- Part Number: CCV3175SR01
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Section : Tenant main breaker
- Voltage : 240 V
- Amperage : 175 A
- Poles : 3
- AIC rating : 10 kAIC
Product Data
- UPC : 786689990510
- Dimensions : 4 in x 8 in x 7 in (Length/Depth x Height x Width)
- Weight : 3
