CCV2150 - Cutler Hammer 150A 2-Pole 120/240V CCV Frame Tenant Main Circuit Breaker, Thermal Magnetic Trip, 10kAIC, UL Listed

CCV2150

CCV2150 is a Cutler Hammer 2-pole tenant main circuit breaker designed for reliable power distribution in commercial and industrial applications.

This Eaton/Cutler-Hammer CCV series breaker features a 150A current rating, 120/240V voltage, and a robust thermal magnetic trip unit for overload and short circuit protection. It is UL listed and suitable for use as a main disconnect in tenant spaces, with a compact L-frame design for easy panel mounting.

Key Specifications
• Part Number: CCV2150
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 150A
• Voltage: 120/240V
• Poles: 2
• Mounting Type: Panel Mount (L-Frame)
• Interrupt Rating: 10 kAIC @ 240V
• Series/Frame: CCV (L-Frame)
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed
• Wire Size: #2/0 AWG to 300 kcmil
• Phase: 1
• Dimensions: 5.4" H x 4.5" W x 7.7" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CCV2150
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Tenant Main
• Type : CCV
• Voltage : 240
• Amperage : 150
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Protection : Thermal Magnetic

Product Data

• UPC : 786685368450
• GTIN : 00786685368450
• Country of Origin : Dominican Republic
• Dimensions : 7.7 in x 5.4 in x 4.5 in (Length/Depth x Height x Width)
• Weight : 2.9
• Certification : UL 489
• Wire Size : AWG 2/0 to 300KCmil, Cu/Al
