Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
CCV2125
CCV2125 is a Cutler Hammer 2 pole thermal magnetic circuit breaker rated for 125 amps and 120/240 volts AC.
This molded case circuit breaker features a CC frame type with thermal magnetic trip protection, suitable for single-phase applications. It has a 10kA interrupting rating at 240 volts, line and load side lug connections, and is UL listed for safety and reliability. The breaker includes long-time and instantaneous trip functions and is designed for feed-thru mounting.
- Key Specifications
- Manufacturer: Cutler Hammer (Eaton)
- Part Number: CCV2125
- Amperage: 125 A
- Voltage: 120/240 VAC
- Poles: 2
- Frame Type: CC
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 10 kAIC at 240 V
- Connection Type: Feed-Thru with line and load side lugs
- Phase: Single-phase
- Certifications: UL Listed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: CCV2125
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Tenant Main
- Type : CCV
- Voltage : 240
- Amperage : 125
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous Trip
- Protection : Thermal Magnetic
Product Data
- UPC : 786685368399
- GTIN : 00786685368399
- Country of Origin : Dominican Republic
- Dimensions : 7.7 in x 5.4 in x 4.5 in (Length/Depth x Height x Width)
- Weight : 2.9
- Certification : UL 489
