Product Info
- Manufacturer:Eaton
- Sub-Category:Parts & Accessories
Description
CCP2B-3-20CF
CCP2B-3-20CF is an Eaton Bussmann series UL98 fusible disconnect rated for 225 amps, 600 Vac, and 125 Vdc with three poles and advanced safety features.CCP2B-3-20CF offers a compact, finger-safe design with lock-on provision, suitable for high-interrupt rating applications up to 200 kAIC. It features bolt-on bus connectors and complies with UL98 standards, making it ideal for industrial and commercial power distribution.
- Key Specifications
- Amperage Rating: 225 A
- Voltage Rating: 600 Vac / 125 Vdc
- Number of Poles: 3
- Interrupt Rating: 200 kAIC
- Mounting Type: Bolt-on bus connector
- Series/Frame: Eaton Bussmann CCPB
- Trip Unit: Fusible disconnect (UL98)
- Special Features: Finger Safe, Lock-On provision
- Certifications: UL98 Listed, CCC Marked
- Product Dimensions: 2.7 in depth, 3.9 in height, 3 in width
- Weight: 3.7 lb
Specifications
- Part Number: CCP2B-3-20CF
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Circuit Breaker
- Item Subcategory : Parts & Accessories
- Section : UL98 fusible disconnect
- Voltage : 125
- Amperage : 20
- Poles : 3
Product Data
- UPC : 051712709385
- Dimensions : 2.7 in x 3.9 in x 3 in (Length/Depth x Height x Width)
- Weight : 3.7
