Product Info
- Manufacturer:Littelfuse
- Sub-Category:Low Voltage Fuse
Description
CCMR-008
CCMR-008 is an 8 amp, 600 volt Class CC time delay fuse from Littelfuse designed for motor circuit protection.This CCMR Series fuse features a dual-element, time-delay (Slo-Blo) design ideal for space-saving protection of motor circuits up to 40 hp. It has a high interrupting rating of 200kA at 600 VAC, providing superior current limiting and Type 2 "No Damage" protection for NEMA and IEC motor components. The fuse is compatible with fuse blocks, clips, or holders and meets UL 248-4 and CSA certifications.
- Key Specifications
- Amperage: 8 Amps
- Voltage Rating: 600 VAC, 300 VDC
- Interrupting Rating: 200 kA at 600 VAC
- Fuse Class: Class CC (Midget)
- Opening Type: Slo-Blo / Time Delay
- Mounting Type: Fuse Block / Clip / Holder
- Series: CCMR
- Certifications: UL Listed, CSA Certified
- Size: Class CC
- Application: Motor circuit protection up to 40 hp
Specifications
- Part Number: CCMR-008
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Powr-Gard
- Type : CCMR
- Voltage : 600
- Amperage : 8
- AIC rating : 200kA@600V
- Connection : Ferrule
- Diameter : 0.41
- Class Rating : CC/CD
- Barrels : 1
Product Data
- UPC : 079458968323
- GTIN : 00079458968323
- Weight : 0.034 lb
