Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
CC3225X
CC3225X is a three-pole, 225A molded case circuit breaker designed for use as a main breaker in commercial and industrial applications. This Cutler Hammer breaker features a high interrupting capacity and is suitable for 120/208Y systems. The CC3225X is a Type CC molded case circuit breaker with a thermal magnetic trip unit and a 10kAIC interrupt rating. It is designed for bolted-on mounting and is compatible with various modular metering stacks. The breaker is suitable for use with copper and aluminum conductors ranging from #2/0 AWG to 300 kcmil.
- Part Number: CC3225X
- Manufacturer: Cutler Hammer
- Amperage Rating: 225 A
- Voltage Rating: 120/208Y VAC
- Number of Poles: Three-pole
- Interrupt Rating: 10 kAIC
- Mounting Type: Bolted-On
- Series/Frame: Type CC
- Wire Size: #2/0 AWG - 300 kcmil Cu/Al
- Trip Unit: Thermal Magnetic
- Certifications: UL 489
- Suitable for use as main breaker
Specifications
- Part Number: CC3225X
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : CC Series
- Type : CC
- Voltage : 240
- Amperage : 225
- Phase : 3
- Poles : 3
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 782114315002
- GTIN : 00782114315002
- Country of Origin : Dominican Republic
- Dimensions : 7.7 in x 5.4 in x 4.5 in (Length/Depth x Height x Width)
- Weight : 2.9
- Certification : UL 489
