CC3100N - Cutler Hammer 100A 240V 3 Pole Main Breaker Kit with 10kAIC Interrupt Rating

CC3100N

CC3100N is a Cutler Hammer main breaker kit designed for reliable circuit protection in residential and commercial applications. This molded case circuit breaker features a 100A current rating, 240VAC voltage rating, and a robust 10kAIC interrupting capacity at 240V. It is a three-pole breaker with thermal/magnetic trip technology and is compatible with Type ECC unit enclosures. The CC3100N is suitable for use with #4-4/0 AWG copper or aluminum conductors and includes a 120V shunt trip for remote operation. This breaker is part of the CC Series and is engineered for feed-thru mounting, providing secure and efficient connections. It meets industry standards for safety and performance, making it ideal for a wide range of electrical distribution needs.

• Part Number: CC3100N
• Manufacturer: Cutler Hammer
• Series: CC
• Amperage: 100A
• Voltage: 240VAC
• Poles: 3
• Interrupt Rating: 10kAIC @ 240V
• Mounting Type: Feed-Thru
• Connection Type: Feed-Thru
• Conductor Size: #4-4/0 AWG Cu/Al
• Trip Unit: Thermal/Magnetic
• Shunt Trip: 120V

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CC3100N
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CC Series
• Type : CC
• Voltage : 240
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 78211465204
• GTIN : 00782114652046
• Dimensions : 7.7 in x 5.4 in x 4.5 in (Length/Depth x Height x Width)
• Weight : 3 lb
• Wire Size : AWG 4 to AWG 4/0, Cu/Al
