Product Info
- Manufacturer:Eaton
Description
CABDYN20-30
CABDYN20-30 is a 30-meter backplane cable for the MTL4500 range of intrinsically safe modules. CABDYN20-30 features a Tyco 20-pin Dynamic range connector with mating connector on one end and free ends on the other for connection to system cards. The cable is designed for remote mounting of intrinsically safe interfaces from control systems. Conductor: 24 strands of 0.2mm diameter (0.75mm²) standard copper. Insulation material: PVC. Current rating: 12A maximum. Operating temperature range: -20°C to +60°C. Key Specifications
- Part Number: CABDYN20-30
- Manufacturer: Eaton
- Cable Length: 30 m
- Connector Type: Tyco 20-pin Dynamic
- Conductor: 24 strands of 0.2mm diameter (0.75mm²) copper
- Insulation Material: PVC
- Current Rating: 12 A
- Operating Temperature: -20°C to +60°C
- Insulation Thickness: 0.5 to 0.8 mm
Specifications
- Part Number: CABDYN20-30
- Manufacturer : Eaton
- Brand : Eaton
- Category : Wire Cord Cable
- Section : Backplane cable
- Connection : Tyco 20-pin Dynamic
- Wire : 24 strands of 0.2mm diameter (0.75mm²) copper
- Amperage Maximum : 12 A
- Operating Temperature Maximum Celsius : -20°C to +60°C
- Material : PVC
- Cable Length : 30 m
Product Data
- GTIN : 03066227676612
