C25DNF340C - Cutler Hammer 3 Pole 40A Definite Purpose Contactor, 440-480V AC Coil, Open with Metal Mounting Plate, C25 Series, CSA/UL Certified

C25DNF340C

C25DNF340C is a Cutler Hammer definite purpose 3 pole contactor designed for reliable motor control in HVAC, refrigeration, and industrial applications.

This non-reversing contactor features a 440-480V AC magnetic coil, open construction with a metal mounting plate, and is part of the C25 series. It offers double quick connect and box lug terminals for flexible installation. The C25DNF340C is CSA and UL certified, RoHS compliant, and suitable for both inductive and resistive loads.

Key Specifications

• Amperage: 40A inductive, 50A resistive
• Voltage: 440-480V AC coil, 600V max
• Poles: 3 (non-reversing)
• Mounting Type: Open with metal mounting plate
• Interrupt Rating: Not specified in available data
• Series/Frame: C25 Series, Frame D
• Trip Unit: Not applicable (standard contactor)
• Certifications: CSA, UL, RoHS, CE
• Terminals: Double quick connect and box lug
• Coil Type: Magnetic
• Enclosure: Open
• Weight: 1.1 lbs net

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 550 VAC coil.

Specifications

• Part Number: C25DNF340C
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 40
• Phase : 3
• Poles : 3
• Configuration : Non-Reversing
• Coil Voltage Maximum : 480
• Coil Voltage Minimum : 440
• Frequency : 50 Hz

Product Data

• UPC : 782116311651
• GTIN : 00782116311651
• Country of Origin : China
• Dimensions : 3.35 in x 2.75 in x 2.4 in (Length/Depth x Height x Width)
• Weight : 1.2 lb
• Certification : CSA Certified UL Recognized UL Listed file E1491 (Guide Number NLDX2)
