Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
C25DNF240H
C25DNF240H is a Cutler Hammer definite purpose contactor rated for 40 amps and 600 volts with a 2 pole configuration and a 277V AC coil.
This contactor is designed for motor control and HVAC applications, featuring a metal mounting plate for panelboard or DIN rail installation. It supports a locked rotor current of 240 amps and includes double quick connect terminals for easy wiring. The C25 series is UL recognized, CSA certified, RoHS compliant, and meets IEC and EN standards, ensuring reliable performance and safety in North American and European markets.
- Key Specifications
- Amperage: 40A
- Voltage Rating: 600VAC max
- Coil Voltage: 277VAC, 60Hz
- Number of Poles: 2
- Mounting Type: Metal mounting plate for DIN rail or panelboard
- Interrupt Rating: Locked Rotor 240A
- Terminals: Double Quick Connect
- Series/Frame: C25
- Certifications: UL Recognized, CSA Certified, RoHS Compliant, CE Mark
- Standards: IEC 60947-4-1, EN 60947-4-1
- Part Number: C25DNF240H
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Family : C25 Series
- Type : C25
- Voltage : 600
- Amperage : 40
- Phase : 1
- Poles : 2
- Configuration : Non-Reversing
- Coil Voltage Maximum : 277
- Coil Voltage Minimum : 277
- Frequency : 50 Hz
- UPC : 782116310814
- GTIN : 00782116310814
- Country of Origin : China
- Dimensions : 3.35 in x 3.75 in x 2.4 in (Length/Depth x Height x Width)
- Weight : 1.3
- Certification : UL Recognized CSA Certified
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Additional Information
This Definite Purpose Contactor includes a 550 VAC coil.
