Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
C25DNF240C
C25DNF240C is a Cutler Hammer definite purpose contactor rated for 40 amps and 600 volts with a 2 pole configuration and a 440/480 volt AC coil.This contactor from the C25 series features a panel mounting type with double quick connect terminals and a metal base plate. It is designed for motor control applications and offers a locked rotor amperage rating of 240A. The device is UL recognized, CSA certified, and RoHS compliant, ensuring reliable performance and safety in North American and European markets.
- Amperage: 40A inductive, 50A resistive
- Voltage Rating: 600VAC maximum
- Coil Voltage: 440VAC at 50Hz, 480VAC at 60Hz
- Poles: 2
- Mounting Type: Panel mount with metal base plate
- Locked Rotor Amps: 240A
- Terminal Connection: Double quick connect and box lug options
- Series/Frame: C25
- Trip Unit: Non-reversing
- Certifications: UL recognized, CSA certified, RoHS compliant
- Application: Motor control systems
Additional Information
This Definite Purpose Contactor includes a 440 VAC coil.
Specifications
- Part Number: C25DNF240C
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Family : C25 Series
- Type : C25
- Voltage : 600
- Amperage : 40
- Phase : 1
- Poles : 2
- Configuration : Non-Reversing
- Coil Voltage Maximum : 480
- Coil Voltage Minimum : 440
- Frequency : 50 Hz
Product Data
- UPC : 782116310791
- GTIN : 00782116310791
- Country of Origin : China
- Dimensions : 3.35 in x 3.75 in x 2.4 in (Length/Depth x Height x Width)
- Weight : 1.19 lb
- Certification : UL Recognized CSA Certified
