C25DNF240B-GL - Cutler Hammer 40A 208-240V 2-Pole Definite Purpose Contactor Open Frame

C25DNF240B-GL

C25DNF240B-GL is a Cutler Hammer definite purpose contactor rated for 40 amps with a 208-240V coil and two poles in an open frame design.This contactor features a non-reversing two-pole configuration with a coil voltage of 208-240 VAC at 50/60 Hz. It supports an inductive load rating of 40A and a resistive load rating of 50A, with a locked rotor amperage of 240A. The unit includes box lug (posidrive setscrew) and quick connect terminals for easy wiring and mounts on a metal plate. It is UL recognized, CSA certified, and RoHS compliant, suitable for HVAC, refrigeration, and other motor control applications.

• Amperage Rating: 40A inductive, 50A resistive
• Coil Voltage: 208-240 VAC, 50/60 Hz
• Number of Poles: 2 (two-pole)
• Type: Non-reversing definite purpose contactor
• Mounting: Open frame with metal mounting plate
• Terminals: Box lug and quick connect
• Locked Rotor Amps: 240A
• Certifications: UL recognized, CSA certified, RoHS compliant
• Frame Size: 15-50A series
• Application: Motor control for HVAC, refrigeration, cranes, elevators

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 208 VAC coil.

Specifications

• Part Number: C25DNF240B-GL
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Voltage : 600
• Amperage : 40
• Phase : 1
• Poles : 2
• Configuration : Non-Reversing
• Coil Voltage Maximum : 240
• Coil Voltage Minimum : 208
• Frequency : 50 Hz

Product Data

• UPC : 786685627724
• Country of Origin : China
• Dimensions : 3.35 in x 3.75 in x 2.4 in (Length/Depth x Height x Width)
• Weight : 1.3
• Certification : CSA Certified UL Listed file E1491 (Guide Number NLDX2)
