Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
C25DNF240B
C25DNF240B is a Cutler Hammer definite purpose contactor designed for reliable motor control in demanding applications.
This two-pole, non-reversing contactor features a 40A inductive amperage rating, 50A resistive rating, and is compatible with 208-240V AC coils. The open-style design includes a metal mounting plate for secure installation, and offers both box lugs and quick connect terminals for flexible wiring. Ideal for HVAC, refrigeration, and industrial equipment, the C25DNF240B is part of the C25 Series, known for compact size and robust performance.
Key Specifications
- Amperage: 40A inductive, 50A resistive
- Voltage: 208-240V AC coil, 600V max
- Poles: 2
- Mounting Type: Open with metal base plate
- Interrupt Rating: Not specified in available data
- Series/Frame: C25 Series, 15-50A frame
- Trip Unit: Not applicable (definite purpose contactor)
- Certifications: CSA Certified, UL Recognized, RoHS Compliant
- Terminals: Box lugs (posidrive setscrew) and quick connect
- Frequency: 50/60 Hz
- Dimensions: 3.35" L x 3.75" H x 2.4" W
- Weight: 1.19 lb
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Additional Information
This Definite Purpose Contactor includes a 208 VAC coil.
Specifications
- Part Number: C25DNF240B
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Family : C25 Series
- Type : C25
- Voltage : 600
- Amperage : 40
- Phase : 1
- Poles : 2
- Temp Rating : -13–158 °F (-25–70 °C)
- Configuration : Non-Reversing
- Coil Voltage Maximum : 240
- Coil Voltage Minimum : 208
- Frequency : 50 Hz
Product Data
- UPC : 782116300402
- GTIN : 00782116300402
- Country of Origin : China
- Dimensions : 3.35 in x 3.75 in x 2.4 in (Length/Depth x Height x Width)
- Weight : 1.19 lb
- Temp Rating : -13–158 °F (-25–70 °C)
- Certification : UL Recognized CSA Certified
