C25DND330T-GL - Cutler Hammer C25 Series 3 Pole 30A 24VAC Definite Purpose Contactor with Metal Mounting Plate

C25DND330T-GL

C25DND330T-GL is a Cutler Hammer C25 Series 3 pole definite purpose contactor rated for 30A at 24VAC, designed for reliable motor control in demanding applications. This contactor features a metal mounting plate, double quick connect terminals, and is suitable for use in heating, air conditioning, elevators, refrigeration, and cranes/hoists. The compact design provides versatility with snap-on side-mounted auxiliaries and optional box terminal lugs for flexible installation. It is RoHS compliant, CSA certified, and UL recognized for use in North America and Europe.

• Part Number: C25DND330T-GL
• Manufacturer: Cutler Hammer
• Series: C25
• Number of Poles: 3
• Amperage Rating: 30A (Inductive), 40A (Resistive)
• Coil Voltage: 24VAC, 50/60 Hz
• Mounting Type: Metal Mounting Plate
• Interrupt Rating: 180A Locked Rotor
• Terminal Type: Double Quick Connect
• Certifications: UL, CSA, RoHS
• Application: Motor Control, HVAC, Elevators, Refrigeration, Cranes/Hoists
• Frame: C25 Series

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This includes a 24 VAC coil.

Specifications

• Part Number: C25DND330T-GL
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 24
• Coil Voltage Minimum : 24

Product Data

• UPC : 786685627632
• GTIN : 00786685627632
• Country of Origin : China
• Dimensions : 3.35 in x 2.5 in x 2.4 in (Length/Depth x Height x Width)
• Weight : 1.05 lb
• Certification : CSA Certified
