C25DND330T - Cutler Hammer 30A 24VAC 3-Pole Definite Purpose Contactor with Mounting Plate

C25DND330T

C25DND330T is a Cutler Hammer definite purpose contactor rated at 30 amps with a 24 VAC coil and three poles, designed for reliable motor control applications.This contactor features a metal mounting plate, double quick connect terminals, and is suitable for use in HVAC, refrigeration, elevators, and crane/hoist applications. It is non-reversing, open type with pressure plate quick connect terminals side-by-side. The device is UL listed, CSA certified, RoHS compliant, and CE marked, ensuring safety and compliance for North American and European markets.

• Amperage: 30A inductive, 40A resistive
• Voltage: 24 VAC coil, 50/60 Hz
• Poles: 3 (three-pole)
• Mounting Type: Metal mounting plate
• Interrupt Rating: Suitable for definite purpose motor control
• Series/Frame: C25 Series, Frame 15-50A
• Trip Unit: Non-reversing
• Terminals: Double quick connect and pressure plate screw terminals
• Certifications: UL Listed, CSA Certified, RoHS Compliant, CE Marked
• Type: Open contactor

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 24 VAC coil.

Specifications

• Part Number: C25DND330T
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• Configuration : Non-Reversing
• Coil Voltage Maximum : 24
• Full Load Amps : Full Load Amps-Inductive 30A Full Load Amps-Resistive 40A
• Coil Voltage Minimum : 24
• Frequency : 50 Hz

Product Data

• UPC : 782116300624
• GTIN : 00661191106560
• Country of Origin : China
• Dimensions : 3.35 in x 2.3 in x 2.4 in (Length/Depth x Height x Width)
• Weight : 1.15 lb
• Certification : UL Listed file E1491 (Guide Number NLDX2) CSA Certified
