C25DND330H - Cutler Hammer 30A 277V 3-Pole Definite Purpose Contactor with Metal Base Plate

C25DND330H

C25DND330H is a Cutler Hammer definite purpose contactor rated for 30 amps, 277 volts AC coil, and three poles, designed for motor control applications.This non-reversing contactor features a 3-pole configuration with a 277 VAC, 60 Hz coil voltage. It mounts via a standard metal base plate and includes double quick connect terminals. The device is UL recognized, CSA certified, and compliant with IEC and EN standards. It supports motor loads up to 5 HP at 230V single-phase and 10 HP at 230V three-phase. Auxiliary contacts can be added for expanded control.

Key Specifications
• Amperage: 30 Amps
• Voltage: 277 VAC coil, 60 Hz
• Number of Poles: 3
• Type: Non-reversing definite purpose contactor
• Mounting: Surface mount with metal base plate
• Terminal Type: Double quick connect
• Power Rating: 5 HP (230V single-phase), 10 HP (230V three-phase)
• Certifications: UL Recognized, CSA Certified, CE Mark, RoHS Compliant
• Standards: IEC 60947-4-1, EN 60947-4-1

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 277 VAC coil.

Specifications

• Part Number: C25DND330H
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• Configuration : Non-Reversing
• Coil Voltage Maximum : 277
• Coil Voltage Minimum : 277
• Frequency : 60 Hz

Product Data

• UPC : 782116308897
• GTIN : 00782116308897
• Country of Origin : China
• Dimensions : 3.35 in x 2.5 in x 2.4 in (Length/Depth x Height x Width)
• Weight : 1.05 lb
• Certification : UL Recognized CSA Certified
