C25DND325H - Cutler Hammer 25A 3-Pole Definite Purpose Contactor 277V Coil

C25DND325H

C25DND325H is a Cutler Hammer definite purpose contactor rated at 25 amps with a 277 volt AC coil and 3 poles.

This contactor is designed for motor control applications and HVAC equipment, featuring double quick connect terminals and a metal mounting plate. It is a direct replacement for Siemens/Furnas 42AF35AG contactors and supports up to 600 volts in 3-phase systems. The compact C25D series offers reliable performance with snap-on side mounted auxiliaries and optional box terminal lugs for versatile installation. This model is UL recognized and CSA certified for use in North America and Europe.

Key Specifications
• Amperage: 25 Amps
• Coil Voltage: 277 VAC, 60 Hz
• Number of Poles: 3
• Voltage Rating: 600 VAC
• Mounting Type: Open with metal mounting plate
• Terminal Type: Double quick connect
• Series/Frame: C25D
• Certifications: UL Recognized, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 277 VAC coil.

Specifications

• Part Number: C25DND325H
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 25
• Phase : 3
• Poles : 3
• Configuration : Non-Reversing
• Coil Voltage Maximum : 277
• Coil Voltage Minimum : 277
• Frequency : 60 Hz

Product Data

• UPC : 782116308606
• GTIN : 00782116308606
• Country of Origin : China
• Dimensions : 3.35 in x 3.75 in x 2.4 in (Length/Depth x Height x Width)
• Weight : 1.19 lb
• Certification : CSA Certified UL Recognized
