Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
C25DND240B
C25DND240B is a 40-ampere, two-pole, non-reversing definite purpose contactor designed for motor control applications with 208-240 Vac, 50/60 Hz coil voltage. This Cutler Hammer contactor features an open enclosure with metal mounting plate and quick connect terminals for reliable performance in HVAC and refrigeration systems. The unit is rated for up to 50 amperes resistive load and 40 amperes inductive full load, making it suitable for controlling motors up to 7.5 horsepower at 230V.
- Amperage Rating: 40A
- Number of Poles: Two-pole
- Type: Non-reversing
- Coil Voltage: 208-240 Vac, 50/60 Hz
- Enclosure: Open with metal mounting plate
- Frame Size: 15-50A, two- and three-pole
- Terminals: Screw/pressure plate and quick connect (side-by-side)
- Connection: Quick
- Resistive Load Rating: 50A
- Inductive Full Load: 40A
- Certifications: UL Recognized, CSA Certified
- Compliance: RoHS Compliant
Additional Information
This Definite Purpose Contactor includes a 208 VAC coil.
Specifications
- Part Number: C25DND240B
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Voltage : 600
- Amperage : 40
- Phase : 1
- Poles : 2
- Configuration : Non-Reversing
- Coil Voltage Maximum : 240
- Coil Voltage Minimum : 208
- Frequency : 50 Hz
Product Data
- UPC : 782116308156
- GTIN : 00782116000000
- Country of Origin : China
- Dimensions : 3.35 in x 3.75 in x 2.4 in (Length/Depth x Height x Width)
- Weight : 1.2
- Certification : UL Recognized CSA Certified
