C25DND230B - Cutler Hammer 30A 208-240V 2-Pole Definite Purpose Contactor

C25DND230B

C25DND230B is a Cutler Hammer definite purpose contactor rated for 30 amps with a 208-240 volt AC coil and two poles.This non-reversing contactor features an open enclosure with a metal mounting plate, double quick connect and screw/pressure plate terminals side-by-side. It is suitable for HVAC, refrigeration, and industrial motor control applications. The C25DND230B is UL recognized, CSA certified, RoHS compliant, and meets IEC and EN standards. It supports inductive loads up to 30A and resistive loads up to 40A, with a locked rotor current rating of 180A. The compact frame size fits 15-50A applications and allows for optional side-mounted auxiliary contacts.

Key Specifications
• Amperage Rating: 30A inductive, 40A resistive
• Coil Voltage: 208-240 VAC, 50/60 Hz
• Number of Poles: 2 (two-pole)
• Type: Non-reversing definite purpose contactor
• Mounting: Open enclosure with metal mounting plate
• Terminals: Double quick connect and screw/pressure plate
• Interrupt Rating: Locked rotor 180A
• Certifications: UL Recognized, CSA Certified, RoHS Compliant
• Frame Size: 15-50A series
• Approvals: IEC 60947-4-1, EN 60947-4-1, CE mark

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 208 VAC coil.

Specifications

• Part Number: C25DND230B
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 30
• Phase : 1
• Poles : 2
• Configuration : Non-Reversing
• Coil Voltage Maximum : 240
• Coil Voltage Minimum : 208
• Compatible Frames : EGE,EGEDC,EGS,EGSDC,EGH,EGHDC,JGE,JGEDC,JGS,JGSDC,JGH,JGHDC,LGE,LGEDC,LGS,LGSDC,LGH,LGHDC,PDG
• Frequency : 50 Hz

Product Data

• UPC : 782116300365
• GTIN : 00661191106362
• Country of Origin : China
• Dimensions : 3.35 in x 3.75 in x 2.4 in (Length/Depth x Height x Width)
• Weight : 1.05 lb
• Certification : UL Recognized CSA Certified
