C25DND230A-GL - Cutler Hammer 30A 2 Pole Definite Purpose Contactor 110-120V Coil, Panel Mount

C25DND230A-GL

C25DND230A-GL is a Cutler Hammer definite purpose contactor designed for reliable motor control applications.This 2 pole contactor features a 30 amp inductive rating and a 110-120 VAC coil voltage operating at 50/60 Hz. It includes double quick-connect and pressure plate terminals, a metal mounting plate for panel mounting, and an open design. The contactor is part of the C25 series and supports up to 40 amp resistive loads. It is suitable for HVAC, automation, and process control applications, offering easy retrofit with a universal mounting plate and snap-on accessories.

Key Specifications
• Amperage: 30A inductive, 40A resistive
• Voltage: 110-120 VAC coil
• Number of Poles: 2
• Mounting Type: Panel mount with metal mounting plate
• Series/Frame: C25
• Contact Configuration: Double break, non-reversing
• Terminal Type: Double quick connect and pressure plate
• Frequency: 50/60 Hz
• Operating Temperature: Up to 150°F
• Certifications: UL recognized, CSA certified, RoHS compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 110 VAC coil.

Specifications

• Part Number: C25DND230A-GL
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Voltage : 600
• Amperage : 30A
• Phase : 1
• Poles : 2
• Configuration : Non-Reversing
• Aux Contacts : 1 NO
• Coil Voltage Maximum : 120
• Coil Voltage Minimum : 110
• Frequency : 50 Hz

Product Data

• UPC : 786685627519
• Country of Origin : China
• Dimensions : 3.35 in x 3.75 in x 2.4 in (Length/Depth x Height x Width)
• Weight : 1.05
• Certification : CSA Certified
