Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
C25DND225C
C25DND225C is a Cutler Hammer definite purpose contactor designed for motor control applications with a 25 amp rating and 2 poles.This contactor features a 440-480 Vac, 50/60 Hz coil voltage and mounts on a metal base plate. It includes pressure plate quick connect terminals arranged side-by-side for easy wiring. The open enclosure design and global listing make it suitable for HVACR and other motor control uses. It is UL listed, CSA certified, and RoHS compliant.
- Amperage: 25A
- Voltage: 440-480 Vac, 50/60 Hz coil
- Poles: 2
- Mounting: Metal base plate
- Connection: Pressure plate quick connect (side-by-side)
- Enclosure: Open
- Series/Frame: D1, 15-50A range
- Certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant
- Type: Non-reversing
- Auxiliary Contacts: Optional side-mounted
- Weight: Approx. 1.19 lb
Additional Information
This Definite Purpose Contactor includes a 440 VAC coil.
Specifications
- Part Number: C25DND225C
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Family : C25 Series
- Type : C25
- Voltage : 600
- Amperage : 25
- Phase : 1
- Poles : 2
- Configuration : Non-Reversing
- Coil Voltage Maximum : 480
- Coil Voltage Minimum : 480
- Frequency : 50 Hz
Product Data
- UPC : 782116307906
- GTIN : 00782116307906
- Country of Origin : China
- Dimensions : 3.35 in x 3.75 in x 2.4 in (Length/Depth x Height x Width)
- Weight : 1.19 lb
- Certification : CSA Certified UL Recognized
