Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
C25DNA340T
C25DNA340T is a Cutler Hammer definite purpose contactor designed for reliable motor control applications with a 40 amp rating and 3 poles.C25DNA340T features a 24 volt AC coil and a metal mounting plate for secure installation. It is UL recognized, CSA certified, RoHS compliant, and suitable for HVAC, refrigeration, and other low duty-cycle motor control uses. This contactor supports inductive loads up to 40 amps and resistive loads up to 50 amps, with a compact design for versatile application.
- Amperage Rating: 40A inductive, 50A resistive
- Coil Voltage: 24 VAC, 50/60 Hz
- Number of Poles: 3
- Mounting Type: Metal mounting plate
- Interrupt Rating: Suitable for HVAC and motor control
- Series/Frame: C25D Series
- Certifications: UL Recognized, CSA Certified, RoHS Compliant, CE Marked
- Auxiliary Contacts: None standard
- Application: Definite purpose for HVAC, refrigeration, elevators, cranes
- Terminal Type: Double quick connect terminals
Additional Information
This Definite Purpose Contactor includes a 24 VAC coil.
Specifications
- Part Number: C25DNA340T
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Voltage : 600
- Amperage : 40A
- Phase : 3
- Poles : 3
- Configuration : Non-Reversing
- Coil Voltage Maximum : 24
- Coil Voltage Minimum : 24
- Frequency : 50 Hz
Product Data
- UPC : 782116305193
- GTIN : 00782116000000
- Country of Origin : China
- Dimensions : 3.35 in x 3.75 in x 2.4 in (Length/Depth x Height x Width)
- Weight : 1.19
- Certification : UL Recognized CSA Certified
