Description
C25BNB220H
C25BNB220H is a Eaton definite purpose contactor designed for motor control applications with a 20 amp rating and 600 volts AC capacity.This two-pole, non-reversing contactor features a C25 frame and is suitable for use with coil voltages of 277 VAC at 60 Hz. It is engineered for reliable switching in HVAC and other low duty-cycle motor and resistive load applications. The contactor includes a metal mounting plate for secure installation and meets UL and CSA certification standards.
- Amperage: 20A
- Voltage: 600V AC max
- Number of Poles: 2
- Frame Type: C25
- Coil Voltage: 277 VAC, 60 Hz
- Type: Non-reversing
- Mounting: Metal mounting plate
- Interrupt Rating: Suitable for definite purpose motor control
- Certifications: UL, CSA
- Application: HVAC, motor control, resistive loads
Additional Information
This Definite Purpose Contactor includes a 440 VAC coil.
Specifications
- Part Number: C25BNB220H
- Manufacturer : Eaton
- Brand : Eaton
- Category : Motor Control
- Item Subcategory : Contactor
- Voltage : 1
- Amperage : 20
- Phase : 1
- Poles : 2
- Configuration : Non-Reversing
- Coil Voltage Maximum : 277
- Coil Voltage Minimum : 277
- Compatible Frames : DK,KDB,KD,HKD,KDC
- Frequency : 50 Hz
Product Data
- UPC : 786685115979
- GTIN : 00786685115979
- Country of Origin : China
- Dimensions : 2.32 in x 3.19 in x 1.97 in (Length/Depth x Height x Width)
- Weight : 0.6
