Product Info
- Manufacturer:Eaton
- Sub-Category:Industrial Control
Description
C0200E3AFB
C0200E3AFB is a Type MTE industrial control transformer from Eaton designed for reliable power distribution in control circuits. This 200 VA single-phase transformer features a primary voltage rating of 208/277V and a secondary voltage output of 120V, making it suitable for standard industrial control applications. The transformer is constructed with copper magnet wire windings and a silicon steel housing, rated for 55 degrees Celsius operation at 50/60 Hz frequency. Screw terminal connections provide secure wiring, and the compact dimensions of 4.5 inches wide by 4.37 inches deep by 5.28 inches high allow for flexible installation in control panels and enclosures. Key Specifications
- Part Number: C0200E3AFB
- Manufacturer: Eaton
- Power Rating: 200 VA
- Primary Voltage: 208/277V
- Secondary Voltage: 120V
- Phase: Single-Phase
- Frequency: 50/60 Hz
- Temperature Rating: 55 degrees Celsius
- Coil Material: Copper Magnet Wire
- Housing Material: Silicon Steel
- Terminal Type: Screw
- Certifications: CSA, ANSI
Specifications
- Part Number: C0200E3AFB
- Manufacturer : Eaton
- Brand : Eaton
- Category : Transformer
- Item Subcategory : Industrial Control
- Family : Type MTE
- Type : C
- Phase : 1
- KVA Rating : 0.2
- Primary Voltage : 208/277
- Secondary Voltage : 120
Product Data
- UPC : 786680550706
- GTIN : 00786680550706
- Country of Origin : United States
- Dimensions : 4.18 in x 5.29 in x 4.5 in (Length/Depth x Height x Width)
- Weight : 9.5
- Certification : CSA Certified,cUL Certified,UL Listed,RoHS Compliant
