BRH240 - Cutler Hammer 40A 240V 2-Pole Plug-On Circuit Breaker 22kA Interrupt Rating

BRH240

BRH240 is a 2-pole, 40 amp, 120/240 Volt plug-on circuit breaker from Cutler Hammer designed for reliable electrical protection.BRH240 features a thermal magnetic trip unit with a common trip mechanism and a high interrupt rating of 22,000 amps at 240 volts. It is part of the BR series and mounts easily with a plug-on method, supporting wire sizes from #14 to #4 AWG copper or aluminum.

• Amperage: 40 A
• Voltage: 120/240 V
• Poles: 2
• Mounting Type: Plug-on
• Interrupt Rating: 22 kA at 240 V
• Series/Frame: BR
• Trip Unit: Thermal Magnetic, Common Trip
• Wire Range: #14-4 AWG Cu/Al
• Phase: Single-phase
• Manufacturer: Cutler Hammer (Eaton)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BRH240
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BR Series
• Type : BRH
• Voltage : 240
• Amperage : 40
• Phase : 1
• Poles : 2
• AIC rating : 22kA@240V
• Connection : Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786676373654
• GTIN : 00786676373654
• Country of Origin : Dominican Republic
• Dimensions : 3 in x 3 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.6
• Certification : UL 490,Federal Specifications Classification W-C376
• Wire Size : AWG 14 to AWG 4, Cu/Al
