BR260NA - Eaton 60A 240V 2-Pole BR Thermal Magnetic Circuit Breaker Plug-On

BR260NA

BR260NA is a Eaton 60 amp, 240 volt, 2-pole thermal magnetic circuit breaker designed for Type BR loadcenters with plug-on mounting.This non-automatic molded case switch features a 5 kA interrupting rating at 240 volts, suitable for use as a disconnect. It supports wire sizes from #8 to 1/0 AWG copper or aluminum and requires two 1-inch spaces for installation. Certified to UL 489 and compliant with Federal Specifications Classification W-C375, it provides reliable circuit protection without magnetic or thermal trip properties.

Key Specifications
• Amperage Rating: 60 A
• Voltage Rating: 240 V
• Number of Poles: 2
• Mounting Type: Plug-on
• Interrupt Rating: 5 kAIC at 240 V
• Series/Frame: BR
• Trip Unit: Non-automatic (thermal magnetic)
• Wire Size: #8-1/0 AWG Cu/Al
• Certifications: UL 489
• Federal Spec: W-C375
• Type: BR 1-Inch plug-on circuit breaker
• Special Feature: Used as disconnect, requires two 1-inch spaces
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: BR260NA
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BR Series
• Type : BR
• Voltage : 240
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 5kA@240V
• Connection : Plug-In
• Functions : NA - No Overcurrent Protection
• Protection : Non-Automatic



Product Data

• UPC : 786676374620
• GTIN : 00786676374620
• Country of Origin : Dominican Republic
• Dimensions : 3 in x 3 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.5
• Certification : UL 489,Federal Specifications Classification W-C375
