Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
BR125
BR125 is a Cutler Hammer Type BR thermal magnetic circuit breaker rated for 25 amps and 120/240 volts with 1 pole. It provides reliable overcurrent protection for residential and commercial electrical systems.BR125 features a 10 kA interrupt rating and a 1-inch plug-on mounting type compatible with Type BR loadcenters. This circuit breaker is UL 489 listed, CSA certified, and meets Federal Specification W-C375 standards. It uses a thermal magnetic trip unit for dependable performance and supports #14-4 AWG wire sizes.
- Key Specifications
- Amperage: 25 A
- Voltage: 120/240 V AC
- Poles: 1
- Interrupt Rating: 10 kAIC
- Mounting Type: 1-inch plug-on
- Series/Frame: Type BR
- Trip Unit: Thermal Magnetic
- Certifications: UL 489, CSA, Federal Spec W-C375
- Wire Range: #14-4 AWG
Specifications
- Part Number: BR125
- Manufacturer : Cutler Hammer
- Brand : EMC
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BR Series
- Type : BR
- Voltage : 120
- Amperage : 25
- Phase : 1
- Poles : 1
- AIC rating : 10kA@120V
- Connection : Plug-In
- Functions : LI - Long-Time and Instantaneous Trip
- Protection : Thermal Magnetic
Product Data
- UPC : 718205134016
- GTIN : 00786676362153
- Country of Origin : Dominican Republic
- Dimensions : 3.3 in x 3.3 in x 1.6 in (Length/Depth x Height x Width)
- Weight : 2.05
- Certification : UL 489,Federal Specifications Classification W-C375
- Wire Size : AWG 14 to AWG 4, Copper/Aluminum
