BQC2252115 - Cutler Hammer 25A 240V 2 Pole Plug-In Circuit Breaker 10kA Interrupt Rating

BQC2252115

BQC2252115 is a Cutler Hammer 2 pole, 240 Volt circuit breaker rated for 25 amperes with a 10kA interrupting capacity.This thermal magnetic quadplex circuit breaker features common trip functionality with two outside poles rated at 15A and a center pole rated at 25A. It is designed for plug-in mounting and is UL listed with a BR frame type, suitable for 1-phase applications at 120/240 VAC.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Part Number: BQC2252115
• Amperage: 25A center pole, 15A outside poles
• Voltage: 120/240 VAC
• Poles: 2 pole (quadplex configuration)
• Mounting Type: Plug-In
• Interrupt Rating: 10kA @ 240V
• Trip Unit: Thermal Magnetic, Common Trip
• Series/Frame: BR Frame, BQC Series
• Certifications: UL Listed, HACR Rated
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: BQC2252115
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQC
• Voltage : 240
• Amperage : 25
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Protection : Thermal Magnetic



Product Data

• UPC : 786676371766
• GTIN : 00786676371766
• Country of Origin : Dominican Republic
• Dimensions : 3 in x 3 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.5
• Standards : HACR Rated, UL Listed
• Certification : UL 489,Federal Specifications Classification W-C390
• Wire Size : AWG 14 to AWG 4, Cu/Al
