BQ2H020 - Siemens 20A 240V 2 Pole Bolt-On Molded Case Circuit Breaker BQ Frame

BQ2H020

BQ2H020 is a Siemens 20 amp, 240 volt, 2 pole bolt-on molded case circuit breaker designed for reliable circuit protection.This Siemens BQ2H020 circuit breaker features a BQ frame with thermal magnetic trip unit, a 10kA interrupting rating at 240V AC, and is HACR rated and UL listed for safety and compliance. It is designed for bolt-on mounting and suitable for residential and commercial electrical panels.

• Amperage: 20A
• Voltage: 240V AC
• Number of Poles: 2
• Mounting Type: Bolt-On
• Interrupting Rating: 10kA @ 240V
• Frame Type: BQ
• Trip Unit: Thermal Magnetic
• Certifications: HACR Rated, UL Listed
• Standards Compliance: UL 489
• Country of Origin: Mexico

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQ2H020
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQ
• Voltage : 240
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-on
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 125A/BQH
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 10 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 783643102507
• GTIN : 00783643102507
• Country of Origin : Mexico
• Dimensions : 2.756 x 1.969 x 3.937 inch
• Weight : 0.705
• Panel Type : Siemens Panelboards
• Standards : HACR Rated, UL Listed
• Certification : CSA, HACR, UL
