BQ2B050QXD - Siemens 50 Amp 2 Pole 120/240V BQ Series Bolt-On Circuit Breaker 10kA Interrupting Rating

BQ2B050QXD

BQ2B050QXD is a Siemens 50 Amp 2 Pole Bolt-On Circuit Breaker designed for reliable circuit protection in residential and commercial applications.This Siemens BQ Series breaker features a thermal magnetic trip unit with long-time and instantaneous trip functions. It is rated for 120/240VAC operation with a 10,000 Amp interrupting rating. The breaker mounts via bolt-on connection and includes load side lug terminals. It is UL listed and CSA approved, ensuring compliance with safety standards.

• Manufacturer: Siemens
• Series: BQ
• Amperage: 50 Amp
• Voltage: 120/240 VAC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupting Rating: 10,000 AIC
• Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
• Terminal Connection: Load Side Lug
• Certifications: UL Listed, CSA Approved

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQ2B050QXD
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQ
• Voltage : 240
• Amperage : 50
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Protection : Thermal Magnetic

Product Data

• UPC : 783643169760
• GTIN : 00783643169760
• Country of Origin : Mexico
• Dimensions : 3.937 x 1.969 x 2.756 inch
• Weight : 0.705
• Panel Type : Siemens Panelboards
• Standards : HACR Rated, UL Listed
• Certification : CSA, HACR, UL
