BPEHD3035 - Eaton 3-Pole 35A 240/480V EHD Frame Circuit Breaker Plug-In Unit

BPEHD3035

BPEHD3035 is an Eaton Pow-R-Way III Old Line circuit breaker plug-in unit designed for busway power distribution systems. This 3-pole, 35-ampere unit operates at 240/480 VAC and features an EHD frame type with 50% internal ground configuration for enhanced safety and grounding flexibility.Technical Specifications: The BPEHD3035 is a breaker-type bus plug rated for 4-wire operation and is fully compliant with NEMA standards. It delivers an interrupt rating of 18 kAIC at 240 VAC and 14 kAIC at 480 VAC, ensuring reliable protection in industrial and commercial power distribution applications. The unit measures 12.36 inches in length, 21.2 inches in height, and 5.43 inches in width, with a product weight of 25 pounds. It is certified by IEEE, CSA, and listed under ANSI UL 857 standards.Key Specifications

• Amperage Rating: 35A
• Voltage: 240/480 VAC
• Poles: 3
• Frame Type: EHD
• Grounding: 50% Internal Ground
• Wire Configuration: 4-Wire
• Interrupt Rating: 18 kAIC at 240V, 14 kAIC at 480V
• Certifications: IEEE, CSA, ANSI UL 857
• Product Weight: 25 lb
• Dimensions: 12.36 in L x 21.2 in H x 5.43 in W

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BPEHD3035
• Manufacturer : Eaton
• Category : Bus Plug
• Item Subcategory : Breaker Type
• Family : Standard Design
• Type : BPEHD
• Voltage : 480
• Amperage : 35
• Phase : 3
• AIC rating : 14kA@480V
• Wire : 3
• Compatible Frames : EHD

Product Data

• UPC : 078668301326
• GTIN : 00786683013260
• Country of Origin : United States
• Weight : 40
• Certification : UL 857,IEEE Certified,ANSI,CSA Certified,NEMA Compliant
