Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
BJL36110
BJL36110 is a PowerPact B molded case circuit breaker designed for industrial and commercial power distribution applications requiring reliable thermal-magnetic protection.
This 3-pole circuit breaker delivers 110 amperes at 600 volts with multiple interrupt ratings across different voltage levels. The unit features thermal-magnetic trip technology and is rated for 80% continuous current operation. It is suitable for both AC and DC applications with dual-rated capability and available in multiple mounting configurations including unit mounts and I-Line installations.
- Amperage: 110A
- Poles: 3
- Voltage: 600Y/347VAC
- Series: PowerPact B
- Trip Type: Thermal-Magnetic
- Interrupt Rating: 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC
- Continuous Current Rating: 80%
- Frequency: 50/60 Hz
- Standards: UL 489
- Dual Rated: AC/DC
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: BJL36110
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : BJL
- Voltage : 600
- Amperage : 110
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Everlink Lug Both Ends
- Frame Size : 125A/BJ
- Temp Rating : -13–158 °F (-25–70 °C)
- MCM Size : Min. Wire Size 14 AWG, 6 AWG Max. Wire Size 2 AWG, 3 AWG
- Breaker Type : Standard
- Protection : Thermal Magnetic
- Phase Connection : ABC
Product Data
- UPC : 785901078555
- GTIN : 00785901078555
- Country of Origin : United States
- Dimensions : 5.4 in (137 mm) x 3.2 in (81 mm) x 3.1 in (80 mm) (Height x Width x Depth)
- Weight : 2.599
- Panel Type : Electrical Distribution Equipment, Industrial Control Panels
- Standards : CSA C22.2 No 5, GB 14048.2, EN/IEC 60947-5-1, UL 489, NEMA AB1, NMX J-266, EN/IEC 60947-2
- Certification : UL, IEC, CCC, EAC, CSA, NOM
- Wire Size : AWG 6...AWG 2/0 fine stranded aluminium/copper
AWG 14...AWG 3/0 rigid or stranded aluminium/copper
