BJL16030 - Square D PowerPact B Frame 30A 1-Pole Circuit Breaker 600V Thermal Magnetic 25kA

Save $198.97
SKU: BJL16030-New
Condition: New
Price:
$384.03 $583.00
Stock:
Low inventory, please call for stock check

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

BJL16030 - Essential Electric Supply
BJL16030 - Square D Feed-Thru 600V 30A 1 pole circuit breaker 65kA@480V - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
BJL16030 - Essential Electric Supply
BJL16030 - Square D Feed-Thru 600V 30A 1 pole circuit breaker 65kA@480V - Essential Electric Supply

Description

BJL16030


BJL16030 is a Square D PowerPact B Frame molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This single-pole breaker features a 30A current rating, 600V AC maximum voltage, and a thermal magnetic trip unit for precise overload and short-circuit protection. It is UL 489 listed and DIN rail mountable for easy installation. Engineered for durability and safety, the BJL16030 breaker offers a 25kA interrupt rating at 600Y/347V AC and is compatible with a wide range of electrical panels. Its compact design and toggle actuator make it suitable for tight spaces and demanding environments.
  • Part Number: BJL16030
  • Manufacturer: Square D
  • Series/Frame: PowerPact B Frame
  • Amperage Rating: 30A
  • Poles: 1
  • Maximum Voltage: 600V AC
  • Interrupt Rating: 25kA @ 600Y/347V AC
  • Mounting Type: DIN Rail
  • Trip Unit: Thermal Magnetic
  • Certifications: UL 489 Listed
  • Actuator Type: Toggle
  • Dimensions: 5.39 in H x 1.06 in W x 4.01 in D
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: BJL16030
  • Manufacturer : Schneider Electric
  • Brand : Schneider Electric
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Powerpact
  • Type : BJL
  • Voltage : 600
  • Amperage : 30
  • Phase : 1
  • Poles : 1
  • AIC rating : 65kA@480V
  • Connection : Feed-Thru
  • Functions : LI - Long-Time and Instantaneous
  • Terminal Connection : Everlink Lug Both Ends
  • Frame Size : 125A/BJ
  • Temp Rating : -13–158 °F (-25–70 °C)
  • MCM Size : Min. Wire Size 14 AWG, 6 AWG Max. Wire Size 2 AWG, 3 AWG
  • Breaker Type : Standard
  • Protection : Thermal Magnetic
  • Phase Connection : Any

Product Data

  • UPC : 606481193912
  • Country of Origin : Mexico
  • Dimensions : 5.4 in (137 mm) x 1.06 in (27 mm) x 3.1 in (80 mm) (Height x Width x Depth)
  • Weight : 1
  • Panel Type : Electrical Distribution Equipment, Industrial Control Panels
  • Standards : NMX J-266, EN/IEC 60947-2, GB 14048.2, CSA C22.2 No 5, UL 489, EN/IEC 60947-5-1, NEMA AB1
  • Certification : UL, IEC, CCC, EAC, CSA, NOM
  • Wire Size : AWG 6...AWG 2/0 fine stranded aluminium/copper
    AWG 14...AWG 3/0 rigid or stranded aluminium/copper
