BJA160205 - Square D 20A 600Y/347VAC 1 Pole PowerPact B Frame Circuit Breaker I-Line Mount

Save $130.59
SKU: BJA160205-New
Condition: New
Price:
$470.41 $601.00
Stock:
12 In stock, ready to be shipped

Same-Day Shipping

Most items ship same-day if ordered by 1:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

BJA160205 - Square D I-Line Style Plug-In 600V 20A 1 pole circuit breaker 100kA@240V - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
BJA160205 - Square D I-Line Style Plug-In 600V 20A 1 pole circuit breaker 100kA@240V - Essential Electric Supply

Description

BJA160205


BJA160205 is a 1 Pole thermal magnetic molded case circuit breaker from Square D designed for reliable circuit protection.This PowerPact B Frame breaker features a 20 Amp current rating and 600Y/347VAC voltage rating with an interrupting capacity of 25kAIC at 600Y/347VAC and 65kAIC at 480V. It uses an I-Line style plug-in mounting and includes long time and instantaneous trip functions for enhanced protection. Certified to UL, CSA, IEC, and other international standards, it supports wire sizes from 14 to 2/0 AWG aluminum or copper.
    Key Specifications
    • Amperage: 20 Amps
    • Voltage: 600Y/347 VAC
    • Number of Poles: 1 Pole
    • Frame Type: PowerPact B (BJA)
    • Mounting Type: I-Line Plug-In
    • Interrupting Rating: 25kAIC at 600Y/347VAC, 65kAIC at 480V
    • Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
    • Certifications: UL, CSA, IEC, EN, CCC, EAC, NOM, NEMA
    • Wire Gauge Range: 14 AWG to 2/0 AWG Aluminum/Copper
    • Operating Temperature: -25 to 70 °C
    • Terminal Connection: Load Side Lug
    • Color: Gray
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: BJA160205
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Powerpact
  • Type : BJA
  • Voltage : 600
  • Amperage : 20
  • Phase : 1
  • Poles : 1
  • AIC rating : 100kA@240V
  • Connection : I-Line Style Plug-In
  • Functions : Long Time and Instantaneous Trip
  • Terminal Connection : I-Line, Lug
  • Frame Size : J
  • Temp Rating : -13–158 °F (-25–70 °C)
  • MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 2/0 AWG (Cu/Al)
  • Protection : Thermal Magnetic
  • Phase Connection : C

Product Data

  • UPC : 606481154180
  • GTIN : 03606480000000
  • Country of Origin : Mexico
  • Dimensions : 5.4 in (137 mm) x 1.06 in (27 mm) x 3.5 in (89 mm) (Height x Width x Depth)
  • Weight : 1.731 lb
  • Standards : EN/IEC 60947-5-1, CSA C22.2 No 5, EN/IEC 60947-2, UL 489, NEMA AB1, NMX J-266, GB 14048.2
  • Certification : UL, IEC, CCC, EAC, CSA, NOM
  • Wire Size : AWG 14...AWG 2/0 aluminium/copper
