BGL36090 - Schneider Electric PowerPact B 90A 3-Pole 600Y/347VAC 18kA Interrupt Rating Molded Case Circuit Breaker, Thermal Magnetic Trip, Clip-On Screw/DIN Rail Mounting, NEMA A Enclosure

BGL36090

BGL36090 is a Schneider Electric PowerPact B series molded case circuit breaker designed for reliable protection in commercial and industrial applications.

This 3-pole circuit breaker features a 90A amperage rating, 600Y/347VAC voltage rating, and an 18kA interrupt rating at 600Y/347VAC. It utilizes a thermal magnetic trip unit for precise overload and short-circuit protection, and is suitable for clip-on screw or DIN rail mounting in NEMA A enclosures. The B frame design ensures robust performance and compatibility with a wide range of electrical systems.

Key Specifications
• Part Number: BGL36090
• Manufacturer: Schneider Electric
• Series/Frame: PowerPact B
• Amperage: 90A
• Voltage: 600Y/347VAC
• Poles: 3
• Interrupt Rating: 18kA at 600Y/347VAC
• Trip Unit: Thermal Magnetic
• Mounting Type: Clip-On Screw/DIN Rail
• Enclosure: NEMA A
• Wire Size: 14 to 2/0 AWG Cu, 14 to 3/0 AWG Al
• Temperature Rating: -25°C to 70°C
• Frequency: 50/60 Hz

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BGL36090
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BGL
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Everlink Lug Both Ends
• Frame Size : 125A/BG
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG, 6 AWG Max. Wire Size 2 AWG, 3 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901076407
• GTIN : 00785901076407
• Country of Origin : Mexico
• Dimensions : 5.4 in (137 mm) x 3.2 in (81 mm) x 3.1 in (80 mm) (Height x Width x Depth)
• Weight : 3.13
• Panel Type : Electrical Distribution Equipment, Industrial Control Panels
• Standards : UL 489, EN/IEC 60947-5-1, NMX J-266, EN/IEC 60947-2, NEMA AB1, GB 14048.2, CSA C22.2 No 5
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 6...AWG 2/0 fine stranded aluminium/copper
  AWG 14...AWG 3/0 rigid or stranded aluminium/copper
