BGA36110 - Square D 110A 600V 3 Pole I-Line Style Plug-In Circuit Breaker, 35kA Interrupt Rating

BGA36110

BGA36110 is a Square D 3 pole, 110 amp, 600 Volt I-Line style plug-in circuit breaker designed for reliable power distribution protection.This thermal magnetic molded case circuit breaker features a 35kA interrupting rating at 480V, suitable for 3 phase applications. It has long time and instantaneous trip functions, a Powerpact B frame, and is designed for reverse fed applications with non-interchangeable trip units. The breaker is rated for 600Y/347VAC voltage and provides high interrupting capacity with ABC phase connection.

Key Specifications
• Amperage: 110A
• Voltage: 600V AC
• Poles: 3
• Interrupt Rating: 35kA @ 480V
• Frame Type: Powerpact B (BGA)
• Mounting Type: I-Line Style Plug-In
• Trip Unit: Thermal Magnetic
• Phase: 3 Phase
• Suitable for Reverse Fed Applications
• Non-Interchangeable Trip
• Voltage Rating: 600Y/347VAC
• Phase Connection: ABC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BGA36110
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BGA
• Voltage : 600
• Amperage : 110
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Al Mechanical Lug OFF End, I-Line ON End
• Frame Size : 125A/BG
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 2 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901056249
• GTIN : 00785901056249
• Country of Origin : United States
• Dimensions : 5.4 in (137 mm) x 3.2 in (81 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 3.201
• Panel Type : Electrical Distribution Equipment, Industrial Control Panels
• Standards : EN/IEC 60947-2, GB 14048.2, NEMA AB1, NMX J-266, EN/IEC 60947-5-1, CSA C22.2 No 5, UL 489
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
