Product Info
- Manufacturer:Schneider Electric
Description
BGA24100Y4
BGA24100Y4 is a Square D PowerPact B series circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This 2-pole, 100A device is rated for 480Y/277VAC systems and features a 35kA interrupting rating for robust fault protection. The breaker utilizes I-Line thermal magnetic trip technology for accurate and consistent operation. This circuit breaker is engineered for use in I-Line busway systems and provides dependable overcurrent protection for branch circuits. Its compact design and high interrupting capacity make it suitable for demanding electrical environments. The device is designed for easy installation and maintenance, ensuring long-term reliability and safety.
- Part Number: BGA24100Y4
- Manufacturer: Square D
- Series: PowerPact B
- Amperage: 100A
- Poles: 2
- Voltage: 480Y/277VAC
- Interrupt Rating: 35kA
- Mounting Type: I-Line
- Frame: PowerPact B
- Trip Unit: Thermal Magnetic
- Width: 54 mm
- Depth: 89 mm
- Height: 137 mm
Specifications
- Part Number: BGA24100Y4
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
Product Data
- UPC : 60648628157
- GTIN : 03606486281574
- Country of Origin : United States
- Dimensions : 5.4 in (137 mm) x 2.1 in (54 mm) x 3.5 in (89 mm) (Height x Width x Depth)
- Weight : 2.879
- Standards : NEMA AB1, NMX J-266, EN/IEC 60947-2, GB 14048.2, CSA C22.2 No 5, UL 489, EN/IEC 60947-5-1
- Certification : UL, IEC, CCC, EAC, CSA, NOM
- Wire Size : AWG 14...AWG 2/0 aluminium/copper
