Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
BDL36125LU
BDL36125LU is a Schneider Electric PowerPact B series thermal magnetic circuit breaker rated for 125 amps and 3 poles with 600Y/347VAC voltage rating.This molded case circuit breaker features a 14kA interrupt rating, lug terminals, and 80% rated continuous current capacity. It is designed for reliable protection in commercial and industrial power distribution applications with control wire on end for easy installation.
- Amperage: 125A
- Voltage Rating: 600Y/347VAC
- Poles: 3
- Interrupt Rating: 14kA
- Breaker Type: Thermal Magnetic
- Mounting Type: Lug
- Series/Frame: PowerPact B
- Continuous Current Rating: 80%
- Control Wire: On End
- Standards: UL 489, IEC 60947-2
Specifications
- Part Number: BDL36125LU
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 600
- Amperage : 125
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 3606481149190
- Country of Origin : United States
- Dimensions : 5.4 in (137 mm) x 3.2 in (81 mm) x 3.1 in (80 mm) (Height x Width x Depth)
- Weight : 2.932 lb
- Standards : UL 489, NEMA AB1, NMX J-266, EN/IEC 60947-5-1, CSA C22.2 No 5, GB 14048.2, EN/IEC 60947-2
- Certification : UL, IEC, CCC, EAC, CSA, NOM
- Wire Size : AWG 6...AWG 2/0 fine stranded aluminium/copper
AWG 14...AWG 3/0 rigid or stranded aluminium/copper
