BDA24100Y2 - Schneider Electric (Square D) PowerPact B 100 A 2-Pole 480Y/277 V Circuit Breaker

Save $147.17
SKU: BDA24100Y2-New
Condition: New
Price:
$689.83 $837.00
Stock:
1 in stock
Limited availability — we'll confirm stock immediately after your order.

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

BDA24100Y2 Schneider Electric - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
BDA24100Y2 Schneider Electric - Essential Electric Supply

Description

BDA24100Y2


BDA24100Y2 is a 2-pole molded-case circuit breaker from the Schneider Electric (Square D) PowerPact B frame, rated at 100 A and designed for 480Y/277 V AC systems. It features a thermal-magnetic trip unit and I-Line plug-in style termination on the line side for rapid installation. This breaker has a breaking capacity of 18 kA at 480Y/277 V and is rated for continuous current at 80% of nameplate in 3-phase systems. It is suitable for distribution and panelboard use in commercial environments requiring compact, high-performance protection.
  • Part Number: BDA24100Y2
  • Manufacturer: Schneider Electric (Square D brand)
  • Series / Family: PowerPact B frame
  • Poles: 2-pole (common trip)
  • Amperage Rating: 100 A
  • Voltage Rating: 480Y/277 V AC
  • Interrupting Rating: 18 kA at 480Y/277 V AC
  • Trip Type: Thermal-magnetic (fixed long-time / instantaneous)
  • Mounting Style: I-Line plug-in line side, lugged load side
  • Connection / Wire Size: AWG 14 to 2/0, aluminum or copper (for I-Line version)
  • Application: Compact distribution feeder breaker for commercial switchboards/panelboards
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: BDA24100Y2
  • Manufacturer : Schneider Electric
  • Brand : Schneider Electric
  • Category : Circuit Breaker
  • Type : BDA
  • Voltage : 480Y/277VAC
  • Amperage : 100
  • Poles : 2
  • AIC rating : 18kAIC@480V
  • Connection : I-Line Style Plug-In
  • Functions : Long Time and Instantaneous Trip
  • Protection : Thermal Magnetic
  • Compatible Frames : BDA

Product Data

  • UPC : 60648115196
  • GTIN : 03606481151964
  • Country of Origin : Mexico
  • Dimensions : 5.4 in (137 mm) x 2.1 in (54 mm) x 3.5 in (89 mm) (Height x Width x Depth)
  • Weight : 3.2 lb
  • Standards : CSA C22.2 No 5, UL 489, EN/IEC 60947-5-1, EN/IEC 60947-2, NEMA AB1, NMX J-266, GB 14048.2
  • Certification : UL, IEC, CCC, EAC, CSA, NOM
  • Wire Size : AWG 14...AWG 2/0 aluminium/copper
