Product Info
- Manufacturer:Schneider Electric
Description
BDA24070Y4
BDA24070Y4 is a Schneider Electric 2 pole circuit breaker rated for 70 amps and 480Y/277VAC voltage, designed for reliable power distribution protection.This PowerPact B series circuit breaker features a thermal magnetic trip unit, suitable for I-Line mounting, with an interrupt rating of 18kA at 480Y/277VAC. It supports 80% continuous current rating and is compatible with MCM size wire and standard frame breakers.
- Amperage: 70 Amps
- Voltage: 480Y/277VAC
- Poles: 2
- Mounting Type: I-Line
- Interrupt Rating: 18kA
- Series/Frame: PowerPact B
- Trip Unit: Thermal Magnetic
- Continuous Current Rating: 80%
- Compatible with MCM size wire
- Standard frame compatibility
Specifications
- Part Number: BDA24070Y4
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Type : BDA
- Voltage : 480Y/277VAC
- Amperage : 70
- Poles : 2
- AIC rating : 18kAIC@480V
- Connection : I-Line Style Plug-In
- Functions : Long Time and Instantaneous Trip
- Protection : Thermal Magnetic
- Compatible Frames : BDA
Product Data
- Weight : 5.19
- Standards : CE, UL, GB, NEMA, EN/IEC, CSA, NMX, CCC, EAC, NOM, RoHS
- Wire Size : AWG 14 to AWG 2/0 Aluminum/Copper
