BDA24070Y2 - Schneider Electric 70A 2 Pole Circuit Breaker 480Y/277VAC I-Line Thermal Magnetic 18kA Interrupting Rating

BDA24070Y2

BDA24070Y2 is a Schneider Electric 2 pole circuit breaker rated for 70 amps and 480Y/277VAC voltage with an 18kA interrupting capacity and I-Line style plug-in connection.

This thermal magnetic molded case circuit breaker features long time and instantaneous trip functions, line and load lug terminal connections, and supports wire gauges from AWG 14 to AWG 2/0 for aluminum or copper conductors. It is part of the BDA series/frame and meets multiple certifications including UL, CSA, CE, IEC, NOM, and RoHS. The breaker is designed for reliable protection in commercial and industrial power distribution applications.

• Amperage: 70A
• Voltage: 480Y/277VAC
• Poles: 2
• Interrupting Rating: 18kA at 480V
• Frame/Series: BDA
• Connection Type: I-Line style plug-in
• Trip Unit: Thermal Magnetic with long time and instantaneous trip
• Terminal Connection: Line and load lug
• Wire Gauge Range: AWG 14 to AWG 2/0 Aluminum/Copper
• Certifications: UL, CSA, CE, IEC, NOM, RoHS
• Actuator Type: Toggle

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BDA24070Y2
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Type : BDA
• Voltage : 480Y/277VAC
• Amperage : 70
• Poles : 2
• AIC rating : 18kAIC@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Protection : Thermal Magnetic
• Compatible Frames : BDA

Product Data

• UPC : 60648115192
• GTIN : 03606481151926
• Country of Origin : Mexico
• Dimensions : 5.4 in (137 mm) x 2.1 in (54 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 2.93 lb
• Standards : EN/IEC 60947-5-1, EN/IEC 60947-2, CSA C22.2 No 5, NMX J-266, UL 489, NEMA AB1, GB 14048.2
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
