BDA24060Y4 - Schneider Electric 60A 2-Pole PowerPact B Molded Case Circuit Breaker 480Y/277V AC 18kA I-Line

BDA24060Y4

BDA24060Y4 is a Schneider Electric PowerPact B Series 2-pole molded case circuit breaker rated for 60 amps and 480Y/277V AC voltage. This circuit breaker features a thermal magnetic trip unit with long time and instantaneous trip functions, an interrupting rating of 18kA at 480/277V AC, and an I-Line style plug-in connection. It supports line and load lug terminal connections and is compatible with wire gauges from AWG 14 to AWG 2/0 aluminum or copper. Certified to multiple standards including UL, CSA, CE, and RoHS, it is designed for reliable electrical protection in commercial and industrial applications.

Key Specifications
• Amperage: 60A
• Voltage Rating: 480Y/277V AC
• Number of Poles: 2
• Interrupting Rating: 18kA at 480/277V AC
• Series/Frame: PowerPact B / BDA
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
• Connection Type: I-Line Style Plug-In
• Terminal Connection: Line and Load Lug
• Wire Gauge: AWG 14 to AWG 2/0 Aluminum/Copper
• Certifications: UL, CSA, CE, RoHS, NEMA, IEC
• Actuator Type: Toggle

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BDA24060Y4
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Amperage : 60
• Poles : 2
• Functions : Long Time and Instantaneous Trip

Product Data

• UPC : 60648115190
• GTIN : 03606481151902
• Country of Origin : Mexico
• Dimensions : 5.4 in (137 mm) x 2.1 in (54 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 3.15
• Standards : CSA C22.2 No 5, EN/IEC 60947-2, NMX J-266, GB 14048.2, NEMA AB1, UL 489, EN/IEC 60947-5-1
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
