BD2015 - Eaton 15A 120V Single-Pole Thermal Magnetic Circuit Breaker 10kAIC Plug-On Type BD

BD2015

BD2015 is a Eaton single-pole thermal magnetic circuit breaker rated for 15 amps and 120 volts with a 10 kA interrupt rating.This Type BD 1-inch CTL plug-on breaker features a rejection tab for proper installation and is designed for use with Eaton BR loadcenters. It carries UL 489 certification and meets Federal Specification W-C375. The breaker supports wire sizes #14-4 AWG Cu/Al and is switch duty rated, suitable for residential and light commercial applications.

Key Specifications
• Amperage: 15 Amps
• Voltage Rating: 120 Volts
• Number of Poles: Single-Pole
• Interrupt Rating: 10 kAIC
• Mounting Type: Plug-On
• Series/Frame: Type BD
• Trip Unit: Thermal Magnetic
• Certifications: UL 489, Federal Spec W-C375
• Wire Size: #14-4 AWG Cu/Al
• Includes Rejection Tab Feature
• Compatible with Eaton BR Loadcenters
• Product Dimensions: 3 in H x 1 in W x 2 in D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BD2015
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BD Series
• Type : BD
• Voltage : 120
• Amperage : 15
• Phase : 1
• Poles : 2
• AIC rating : 10kA@120V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Protection : Thermal Magnetic

Product Data

• UPC : 786676369206
• GTIN : 00786676369206
• Country of Origin : United States
• Dimensions : 2 in x 3 in x 1 in (Length/Depth x Height x Width)
• Weight : 0.38
• Certification : UL 489,Federal Specifications Classification W-C375
• Wire Size : AWG 14 to AWG 4, Cu/Al
