BD1515 - Eaton 15A 120V Single Pole Type BD 1-Inch CTL Plug-On Circuit Breaker, 10 kAIC, BR Series, Thermal Magnetic Trip, UL 489

BD1515

BD1515 Eaton BR thermal magnetic circuit breaker provides reliable overcurrent protection for residential and light commercial electrical panels.

This Type BD 1-Inch CTL plug-on circuit breaker features a rejection tab for secure installation and is designed for use with Type BR loadcenters. It is suitable for both copper and aluminum wiring, offers a high interrupt rating, and carries essential certifications for safety and performance.

Key Specifications
• Amperage: 15A
• Voltage: 120V
• Poles: Single-pole
• Mounting Type: Plug-on
• Interrupt Rating: 10 kAIC
• Series/Frame: BR, Type BD
• Trip Unit: Thermal magnetic
• Certifications: UL 489, Federal Specifications Classification W-C375, HACR listed
• Wire Size: #14-4 AWG Cu/Al
• Dimensions: 2.9" L x 2.5" H x 1" W
• Weight: 0.35 lb
• Switch Duty Rated: Yes (15A single pole)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BD1515
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BD Series
• Type : BD
• Voltage : 150
• Amperage : 15
• Phase : 1
• Poles : 2
• AIC rating : 10kA@120V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 4 AWG (Cu/Al)
• Breaker Type : BR
• Protection : Thermal Magnetic

Product Data

• UPC : 786676369053
• GTIN : 00786676369053
• Country of Origin : Dominican Republic
• Dimensions : 2.9 in x 2.5 in x 1 in (Length/Depth x Height x Width)
• Weight : 0.35
• Panel Type : Type BR Loadcenters
• Standards : UL 489
• Certification : UL 489
• Wire Size : AWG 14 to AWG 4, Cu/Al
