Product Info
- Manufacturer:WEG
- Sub-Category:Contactor And Motor Starter Auxiliary
Description
BCXML11
BCXML11 is a WEG auxiliary contact block designed for motor control applications, featuring a 1 normally open and 1 normally closed contact configuration.
This auxiliary contact block mounts on the side of WEG CWM series contactors rated from 9 to 105 amps, providing reliable switching with screw terminals and a compact design. It supports a maximum operating/insulation voltage of 660/690 volts and a contactor current range of 50 amps. The BCXML11 is an authorized replacement for the GE BCLL11 auxiliary contact and is compatible with CWM9 through CWM300 contactors, offering flexible auxiliary contact arrangements when combined with other blocks.
- Part Number: BCXML11
- Manufacturer: WEG
- Contact Configuration: 1 Normally Open (NO) + 1 Normally Closed (NC)
- Number of Poles: 2
- Mounting Type: Side Mount
- Contactor Current Range: 50 Amps
- Operating/Insulation Voltage: 660/690 Volts (Ui max)
- Terminal Type: Screw Terminals
- Compatible With: WEG CWM Series Contactors (9 to 105 Amps and up to CWM300)
- Weight: Approximately 0.117 lbs
- Replacement For: GE BCLL11 Auxiliary Contact
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: BCXML11
- Manufacturer : WEG
- Brand : WEG
- Category : Motor Control
- Item Subcategory : Contactor And Motor Starter Auxiliary
- Family : CWM Series
- Type : BCXML
- Configuration : 1NO/1NC
Product Data
- UPC : 090355031100
- Country of Origin : Brazil
- Weight : 5 lb
