Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage
Description
BBU27-6K
BBU27-6K is a 6 amp, 27 kV AC boric acid medium voltage fast blow fuse from Eaton's Bussmann Electrical Division.
This cartridge-type fuse features a fast blow response time (K-speed) and is designed for medium voltage applications up to 27 kV AC. It includes an indicator pin for visual status indication and is part of the BBU series of boric acid expulsion fuses. The fuse has an interrupting rating of 12.5 kA at 27 kV and meets ANSI C37.40 service conditions. End fittings are required to complete the electrical connection between the fuse and live parts.
- Key Specifications
- Amperage: 6 Amps
- Voltage Rating: 27 kV AC
- Fuse Type: Boric Acid Medium Voltage
- Speed: Fast Blow (K)
- Indicator Style: Indicator Pin
- Interrupt Rating: 12.5 kA at 27 kV
- Series: BBU
- Mounting Type: Cartridge
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: BBU27-6K
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage
- Section : Expulsion fuse
- Type : BBU
- Voltage : 27000
- Amperage : 6
- AIC rating : 12.5kA@17kV
- Connection : Ferrule
- Diameter : 1.24
- Barrels : 1
- Velocity : Fast
Product Data
- UPC : 743172087768
- GTIN : 00051712670388
- Dimensions : 22.5 in x 1.44 in x 1.44 in (Length/Depth x Height x Width)
- Weight : 2.5
