2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
BBU27-140K
BBU27-140K is a medium voltage boric acid expulsion fuse designed for industrial power distribution systems operating up to 27,000 VAC. This fast-blow fuse provides reliable circuit protection for transformers, feeder circuits, distribution equipment, and metal-enclosed switchgear in demanding industrial environments. The fuse features visual indication through end fittings and meets ANSI C37.40 standards for service conditions and definitions. Key Specifications
- Current Rating: 140 A
- Voltage Rating: 27 kVAC
- Speed Classification: K (Fast Blow)
- Fuse Type: Boric Acid Expulsion
- Interrupting Rating: 12.5 kA at 27 kV
- Visual Indicator: Indicator Pin with End Fittings
- Mounting: End Fittings Required
- Standards: ANSI C37.40
- Applications: Power Transformers, Feeder Circuits, Distribution Transformers, Switchgear
Specifications
- Part Number: BBU27-140K
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Type : BBU
- Voltage : 27000
- Amperage : 140
- AIC rating : 12.5kA@17kV
- Connection : Ferrule
- Diameter : 1.24
- Barrels : 1
- Velocity : Fast
Product Data
- UPC : 051712670517
- GTIN : 00051712670517
- Dimensions : 22.5 in x 1.44 in x 1.44 in (Length/Depth x Height x Width)
- Weight : 2.5
