Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage Fuse
Description
BBU17-65E
BBU17-65E is a 65 amp, 17 kV medium voltage boric acid expulsion fuse from Eaton's Bussmann series designed for indoor power distribution protection.
This fuse features a standard speed (E class) fuse element with a 14 kA interrupting rating at 17 kV. It uses a fiberglass reinforced resin tube housing with plated copper contacts and a visual indicator pin for fuse status. The BBU17-65E is a single barrel fuse suitable for use with appropriate end fittings to complete electrical connections and mounting in medium voltage applications.
- Current Rating: 65 Amps
- Voltage Rating: 17 kV AC
- Fuse Type: Boric Acid Expulsion
- Speed Class: E (Standard)
- Interrupting Rating: 14 kA at 17 kV
- Housing: Fiberglass reinforced resin tube
- Contacts: Plated copper
- Indicator: Visual indicator pin
- Mounting: Requires compatible end fittings
- Series: Bussmann BBU
- Application: Indoor medium voltage power distribution
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: BBU17-65E
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Type : BBU
- Voltage : 14400
- Amperage : 65
- AIC rating : 14kA@17kV
- Connection : Ferrule
- Diameter : 1.24
- Barrels : 1
- Velocity : Standard
Product Data
- UPC : 051712670173
- Dimensions : 19.1 in x 1.44 in x 1.44 in (Length/Depth x Height x Width)
- Weight : 2.13
